Linear ground-recessed luminaire with DMX RGBW 3535 LEDs, lengths 310/600/900/1200 mm, same body, tilt ±15°, built-in driver 220–240V (310mm uses remote 24V), IP67 IK10.
Wave
2.0
Dmx Rgbw
401102
-
Wattage
4.5W
-
CCT
RGBW
-
Beam Angle
.BL
-
Lumens
160
-
Finish
RAL7016 -
IP Rating
IP65
-
IK Rating
IK08
-
Coating
Polyester powder coating with phosphocromating pre-finish
-
Light source
1 x CREE XML COLOR RGBW LED
-
Screws
Stainless steel
-
Transformer
Constant voltage 24V DC remote driver needed
-
Gasket
Silicone rubber
-
Glass
Tempered
-
Power cable
1 mt. power cable included
-
Gross weight
1,00 Kg
REMOTE DRIVER SELECTION
| Meanwell | LPV-20-24 | constant voltage 24V DC | 20W | IP67 | min 1 - max 3 |
| Meanwell | LPV-35-24 | constant voltage 24V DC | 35W | IP67 | min 1 - max 6 |
Integrated Accessories
401102.RW.BL.02.X. _ _
Built-in accessories to be requested when ordering
example 401102.RW.BL.02.X.HC
.00
NO ACCESSORY
No accessory
